OnePlus Nord 5 5G 8GB/256GB
- Overview
- Technical Specifications
Network
Technology
GSM / HSPA / LTE / 5G
2G bands
GSM 850 / 900 / 1800 / 1900
3G bands
HSDPA 850 / 900 / 1900 / 2100
4G bands
1, 2, 3, 4, 5, 7, 8, 12, 17, 18, 19, 20, 26, 28, 32, 38, 39, 40, 41, 42, 66
5G bands
1, 2, 3, 5, 7, 8, 12, 20, 28, 38, 40, 41, 66, 75, 77, 78 SA/NSA
Body
Dimensions
163.4 x 77 x 8.1 mm (6.43 x 3.03 x 0.32 in)
Build
Glass front (Gorilla Glass 7i), glass back, plastic frame
Additional Features
IP65 dust tight and water resistant (low pressure water jets)
Display
Type
Swift AMOLED, 1B colors, 144Hz, 3840Hz PWM, HDR10+, 800 nits (typ), 1400 nits (HBM), 1800 nits (peak)
Size
6.83 inches, 113.3 cm2 (~90.1% screen-to-body ratio)
Resolution
1272 x 2800 pixels (~450 ppi density)
Protection
Corning Gorilla Glass 7i, Mohs level 6
Additional Features
Ultra HDR image support
Platform
OS
Android 15, up to 4 major Android upgrades, OxygenOS 15
Chipset
Qualcomm SM8635 Snapdragon 8s Gen 3 (4 nm)
CPU
Octa-core (1x3.0 GHz Cortex-X4 & 4x2.8 GHz Cortex-A720 & 3x2.0 GHz Cortex-A520)
Camera
Primary
Dual Camera
- 50 MP, f/1.8, 24mm (wide), 1/1.56", 1.0µm, PDAF, OIS
- 8 MP, f/2.2, 15mm, 116˚ (ultrawide), 1/4.0", 1.12µm, AF
Features
LED flash, Ultra HDR, panorama
Video
4K@30/60fps, 1080p@30/60/120fps, gyro-EIS
Secondary
- 50 MP, f/2.0, 21mm (wide), 1/2.76", 0.64µm, AF
- Panorama
- 4K@30/60fps, 1080p@30/60fps; gyro-EIS video recording
Sound
Loudspeaker
Yes, with stereo speakers
Additional Features
24-bit/192kHz Hi-Res audio
Comms
WLAN
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct
Bluetooth
5.4, A2DP, LE, aptX HD, LHDC 5
GPS
GPS, GLONASS, GALILEO, BDS, QZSS, NavIC
Features
Sensors
Fingerprint (under display, optical), accelerometer, gyro, proximity, compass
Battery
Battery
- 6800 mAh
- 80W wired, 33W PPS, 18W PD, 100% in just 54 min
- 5W reverse wired
- Bypass charging
